DXE 80

Indirect gas-fired heater, 80 kW

  • Sealed combustion system
  • No CO2 introduced into the space
  • Installed outside the building
  • Up to 25% energy savings
  • Reliable design
DXE 80

Indirect gas-fired heater, 80 kW

  • Sealed combustion system
  • No CO2 introduced into the space
  • Installed outside the building
  • Up to 25% energy savings
  • Reliable design

Description

The DXE 80 is available in natural gas or propane gas. The DXE has a closed combustion chamber. CO2 and water vapour are discharged outside.
The DXE is designed for installation outside the building. The advantage for the farmer is that everything is outside , except the door for cleaning.

Also, if it is not allowed to install a gas supply line within the farm the DXE is an excellent heating solution.
An extra discharge cone is available to guide the flow of warm air along the side of the farm as well as DXF fans.

Features

  • well-proven technology
  • controls & burner accessible by door
  • insulated splash proof casing
  • easy access due to outside location
  • reduction of bio hazard
  • on/off control as standard
  • modulating control possible
  • 0-10 V. analogue input natural gas or propane
  • supplied with adjustable legs and wall flanges
  • optional: discharge cone (optional)

Technical features

Nominal power 75.9kW
Efficiency 91.5%
Air volume 0m³/h - 8000m³/h
Max. throw horizontal 45m
Max. throw vertical 0m
Supply voltage 230V
Nominal current 3.9A
Max. electric power input 900W
Max. sound level (at a distance of 4 metres) 70dB(A)
Material heat exchanger Stainless steel
Closed version Yes
Burner controller high/low No
Modulating burner control Yes
Control signal on/off Yes
Control signal 0-10 V No
Fan type Axial
Degree of protection (IP) IPX4D
Height 760mm
Width 1030mm
Depth 2270mm
Weight 150kg
Outer pipe diameter combustion air 130mm
Fuel connection External thread
Nominal diameter fuel 3/4 inch (20)
Gas consumption low-calorific natural gas (G25) 9.9m³/h
Gas consumption propane (G31) 6.6kg/h

Images

Accessories

Aansturingen
Overig

Service parts

View our service parts for the DXE 80 (and earlier models) in the parts shop.

Parts shop

DXE Heaters

The Winterwarm DXE is a gas-fired warm air heater for poultry sheds, designed to be installed outside the building.

All Winterwarm DXE types
